SONY TC-388-4

SONY TC-388-4

€1,900.00
TC-388-4
Four Channel Quadraphonic Tapecorder
REEL TO REEL
4 tracks
19
Specifications

Track system: 4-track, 4-channel, stereo/multi channel system

Heads: 1 x playback, 1 x record, 1 x erase

Reel size: up to 7 inch reel

Tape speeds: 3 3⁄4  7 1⁄2 ips

Wow and flutter: 0.09% (7 1⁄2 ips)

Frequency response: 20Hz to 30kHz (7 1⁄2 ips)

Signal to Noise Ratio: 55dB

Total harmonic distortion: 1.2%

Input: 60mV (line), 0.2mV (mic)

Output: 0.775V (line)

Semiconductors: 20 x IC, 35 x transistors, 12 x diodes

Dimensions: 16-5/8 x 19-7/8 x 8-11/16 inches

Weight: 31lbs

Data sheet

Frequency response
20-20000Hz
Capstan
Single capstan
Date of manufacturing
1974
Availability
DISPONIBLE
Localisation
BOURG-LA-REINE
Presentation
Façade alu et coffret bois
Motor
3 motors
Comments
Accessoires non compris dans le prix de base ( bobines noyaux etc.)
Poids
15 kg
Stereo / Mono
Quadraphonic
Connectors
RCA / Cinch
Technology
Transistors
Drive method
A courroie
Vu-meters
Needle
Speeds
19 et 38 cm/s
